Core I5-4200U Mini ITX board 2 Lan, 3 Display, 6 COM 15 W HD4400 smart mini pc board

FOB Reference Price:Get Latest Price
$173.00 - $188.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock
Application:
Desktop
Chipset Manufacturer:
Intel
Socket Type:
Other
Form Factor:
Mini-ITX
Memory Type:
DDR3
Graphics Card Type:
Integrated
Hard Drive Interface:
SATA, Mini PCIE
FSB / HT:
2.6GHz
Brand Name:
intel
Model Number:
Q4200UG2-P
Place of Origin:
Guangdong, China
CPU:
Intel Core i5 4200U Processor (3M Cache, 2.6 GHz, Haswell)
Model:
Q4200UG2-P
Supply Ability
Supply Ability:
5000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
30 pcs/carton
Port
shenzhen
Lead Time :
Shipped in 3 days after payment
Product Description
TYPE
Description
Mechanical standard
3.5" Industrial Motherboard
148mm x 104mm
Processor
Intel Core i5 4200U Processor (3M Cache, 2.6 GHz, Haswell)
With up to 15 W TDP
BIOS
AMI BIOS
64MBit BIOS
Memory
One 204-pin DDR3 SDRAM Small Outline (SO-DIMM) socket
Support DDR3L 1600 MHz SO-DIMM 1.35V
Support 8GB Max
Graphics
Intel HD Graphics 4400
Display: VGA / HD Video Three Display
* 2 x HD Video (port), 1 x VGA (header)
LAN
2 x Intel I211-AT 1000M
Audio
Realtek ALC662 HD Audio Decoding controller
6 Channel Audio output
Line out + MIC IN Port
COM
6 x COM port ( RS485 optional )
USB
2 x On-board USB 2.0
4 x On-board USB 3.0
2 x Pin interface USB 2.0
1 x SATA 3.0 (6Gb/s)
1 x Mini PCIE port
Expansion Port
1 x PCI E xpress Full-Mini Card connector ( for mSATA SSD )
1 x PCI E xpress Half-Mini Card connector ( for WIFI and Bluetooth )
1 x SIM port (optional)
1 x SATA power connector
1 x SATA 3.0 connector (6Gb/s)
1 x DDR3 SO-DIMM socket
1 x Front panel header
6 x Serial port headers ( RS485 optional )
1 x D-sub header
1 x GPIO header
1 x Automatically boot jumper
2 x USB 2.0 header
1 x Audio header
Front Panel
1 x Push button for Power ON/OFF
1 x Power LED
1 x HDD LED
2 x USB 3.0 ports
2 x USB 2.0 ports
Black Panel
1 x DC in connector
2 x HD Video Connectors
2 x RJ45 1000M ports
2 x USB 3.0 Ports
1 x Mic in port
1 x Speaker out port
Power Supply
DC 12V
Working condition
Operation Temperature -10º-50ºC
Operation Humidity 10%-90% Relative Humidity,
Non-Condensing
Accessories
Cable for SATA HDD
Detailed Images
